Higrometer Dinding Fantini Cosmi 2 outlet L24EM2 230V

L24EM2 humidistat, wall mounting For humidification or dehumidification systems with 2 outlets. 53 110 75 96 Dimensions (mm) Sensor Num Power supply Measuring Resolution Measuring Degree of outputs range accuracy protection RH% RH% (0-100 RH%) L24EM2 probe (LS160A) 2 230 Vac 0 - 100 1 <± 0.7 IP55 ELECTRICAL CHARACTERISTICS Output on single-pole relay in deviation. Power consumption 2W. Contact rating 8(3)A 240 Vac for each output. REGULATIONS AND APPROVALS Compliant with EN60730-2-9, EN60730-1, EN55022 (CLASS B), EN50082-1. INSTALLATION Wall mounting. 18 OPERATION Type of control: can operate in ON/OFF or PID mode. ON/OFF control: in ON/OFF mode the output is ON or OFF depending on the input humidity, setpoint (1SP) and hysteresis value (1HY). The hysteresis indicates the amplitude of the deviation of the setpoint humidity to reactivate the output. PID control: in PID mode the output is ON for a fraction of cycle time 1CT. The cycle time characterises the dynamics of the system to be controlled and influences the accuracy of the control. Proportional control. Integrative proportional control. FEATURES Configurable parameters: „ dehumidification or humidification function by assigning positive or negative sign to the differential respectively; „ minimum or maximum setpoint limits; „ ON or OFF status of the output in the event of a defective probe; „ minimum OFF time of the output. Operating temperature -10 to 50°C. ACCESSORIES LS160A RH% probe, scale range from 0 to 100 %RH. L 19
