Preciman Stainless steel pressure gauge axial D63 0/+160Mbar G1/4 - Measurement
PrecimanMeasurement

Preciman Stainless steel pressure gauge axial D63 0/+160Mbar G1/4

Preciman menghadirkan pressure gauge stainless steel axial D63 dengan rentang tekanan 0/+160 mbar dan koneksi G 1/4. Alat ukur ini dirancang khusus untuk sistem pneumatik bertekanan rendah, cocok untuk media gas atau…

SKU 3G-CBM-06281

Juga terdaftar sebagai: ROS 23010 · ROS-23010

Merek
Preciman
Item
Stainless steel pressure gauge axial D63 0/+160Mbar G1/4
Kategori
Measurement
UNSPSC
41112412 — Pressure gauge
Tersedia untuk Dipesan
Stok tersedia & bea cukai ditangani
  • 6–10 business days door-to-door; Bea Cukai clearance typically 3–5 business days.
  • Invoicing in IDR or USD. Bank transfer and corporate PO accepted.
  • Dikirim ke: Jakarta, Surabaya, Bandung, Medan, Batam
Harga dagang sesuai penawaran — balasan dalam 24 jam
Jumlah
WhatsApp seorang insinyurMessage via Telegram
Tidak perlu akun — permintaan penawaran Anda langsung masuk ke tim insinyur kami. Akun gratis memungkinkan Anda melacak penawaran dan memesan ulang lebih cepat.
Pengiriman ke Seluruh Dunia
Pengiriman udara & laut
Lembar Data Atas Permintaan
Spesifikasi teknis
Penawaran 1 Hari
Balasan dalam 24 jam

Local availability & support — Indonesia

Phone
+65 8878 8355

Spesifikasi Teknis

Preciman
accuracy
±1.6% of full scale
connection
G 1/4
gauge size
63 mm (2.5 inch)
wetted parts
Copper alloy
case material
Stainless steel
pressure range
0/+160 mbar

Konten Lembar Data

Manomètre ROS20002 à 16 Name : Capsule gauge Application : Low pressure pneumatic systems Suitable for fluid medium, gaseous or dry that does not corrode copper alloy. Low pressure series Copper alloy wetted parts & stainless steel case Specifications : Size : 2.5”(63mm) , 4” (100mm), 6“（150mm） Accuracy : +-1.6% of full scales Range available ( no stock) : 10 "H2O to 240 "H2O (25 to 600 mbar) or other equivalent units of pressure or vacuum Working Pressure : Steady : full scale Fluctuating : 0.9 x full scale Operating Temperature Ambient: -4°F to 140°F (-20°C to +60°C) Media: max. 140°F (+60°C) Service Fluid : compatible gases and liquids Housing: Stainless steel and Bayonet bezel . Windows : glass window . Capsule : Copper- alloy Movement : full-copper alloy Connection : brass 1/8” OR 1/4” for 2.5”(63mm) , 3/8” OR 1/2” for 4” (100mm) , 6”(150mm) Thread : BSP , BSPT, NPT ,or metric thread. Dials: aluminum White background Black or black and red lettering . With customer logo is available . Scale Unit : in. H2O/mm H2O oz.-sq. in./mm H2O oz.-sq. in./in. H2O PSI Optional extras Zero ajustable .
Tidak yakin ini adalah suku cadang yang tepat? Minta rekomendasi.

Butuh bantuan pemasangan atau rekayasa?

Instalasi, komisioning, rencana pemeliharaan, desain sistem, dan penawaran produk + layanan bundel — satu tim menangani cakupan penuh.
Bicaralah dengan seorang insinyur

Ajukan pertanyaan

Preciman Produk
3G Electric (S) Pte. Ltd. — Singapore

Deskripsi Produk

Preciman menghadirkan pressure gauge stainless steel axial D63 dengan rentang tekanan 0/+160 mbar dan koneksi G 1/4. Alat ukur ini dirancang khusus untuk sistem pneumatik bertekanan rendah, cocok untuk media gas atau cairan kering yang tidak korosif terhadap paduan tembaga. Dengan akurasi ±1.6% dari skala penuh, gauge ini menjadi pilihan andal untuk aplikasi pengukuran tekanan di industri. Cari pressure gauge axial untuk kebutuhan Anda? Produk ini tersedia sebagai bagian dari peralatan industri dari 3G Electric.

Supplied to Indonesia — compatible with 50 Hz installations. DHL Express delivery to Jakarta, Surabaya, Bandung, customs and duties handled door-to-door.

Pertanyaan yang Sering Diajukan

Apa spesifikasi pressure gauge Preciman D63 0/+160 mbar?

Pressure gauge Preciman ini memiliki ukuran 63 mm (2.5 inci), rentang tekanan 0/+160 mbar, koneksi G 1/4, akurasi ±1.6% dari skala penuh, bagian basah dari paduan tembaga, dan casing stainless steel. Cocok untuk sistem pneumatik bertekanan rendah.

Untuk apa pressure gauge Preciman D63 digunakan?

Pressure gauge Preciman D63 digunakan untuk mengukur tekanan pada sistem pneumatik bertekanan rendah, seperti pada peralatan industri yang menggunakan media gas atau cairan kering yang tidak korosif terhadap paduan tembaga. Rentang tekanan 0/+160 mbar dan akurasi ±1.6% memastikan pembacaan yang presisi.

Di mana beli pressure gauge Preciman D63 0/+160 mbar di Indonesia?

Anda dapat membeli pressure gauge Preciman D63 0/+160 mbar melalui 3G Electric, distributor resmi yang memasok dan mengirimkan peralatan industri ke seluruh Indonesia. Kami menangani logistik dan bea cukai untuk memastikan produk sampai ke lokasi Anda.

Bagaimana cara memilih pressure gauge yang tepat untuk sistem pneumatik?

Pilih pressure gauge dengan rentang tekanan yang sesuai, seperti Preciman D63 0/+160 mbar untuk tekanan rendah. Pastikan koneksi (G 1/4), ukuran (63 mm), dan material bagian basah (paduan tembaga) kompatibel dengan media dan sistem Anda. Akurasi ±1.6% dari skala penuh memberikan keandalan pengukuran.

Digunakan dalam

Aplikasi umum untuk Preciman
Boiler steam-system monitoring — Preciman D100 glycerin gauges (0–40 bar) mounted on boiler headers and steam-outlet lines.
Pump discharge pressure indication — Preciman D63 axial stainless gauges (0–250 bar) on centrifugal-pump outlet manifolds and pressure-relief test points.
Compressed-air and vacuum systems — Preciman vacuum and low-range gauges (−1 to +0 bar, 0–1.6 bar) on air-treatment equipment and vacuum pumps.
Hydraulic-circuit monitoring — Preciman all-stainless manometers (D63 vertical, up to 250 bar) on hydraulic-press and industrial-lifting-system manifolds.
Fuel-gas and burner control lines — Preciman D63 low-range gauges (0–1 bar, 0–2.5 bar) on natural-gas and LPG regulator outlet monitoring.
Heat-exchanger and thermal-loop diagnostics — Preciman glycerin D63/D100 gauges for hot-water circulation and process-steam secondary loops.
