CRYDOM Solid State Relay: DIN-Rail & Surface Mounted, 30 A Max Output Current - Combination DIN-Rail & Surface-Mounted Relays
CRYDOMCombination DIN-Rail & Surface-Mounted Relays

CRYDOM Solid State Relay: DIN-Rail & Surface Mounted, 30 A Max Output Current

The CRYDOM Solid State Relay (MPN CKM0630) is a combination DIN-rail and surface-mounted relay with a DC output. It features a Form A switch configuration, an output voltage range of 0 to 60V DC, and a maximum output…

SKU 3G-OTH-38097

Merek
CRYDOM
Item
Solid State Relay: DIN-Rail & Surface Mounted, 30 A Max Output Current
Kategori
Combination DIN-Rail & Surface-Mounted Relays
Tersedia untuk Dipesan
Stok tersedia & bea cukai ditangani
  • 6–10 business days door-to-door; Bea Cukai clearance typically 3–5 business days.
  • Invoicing in IDR or USD. Bank transfer and corporate PO accepted.
  • Dikirim ke: Jakarta, Surabaya, Bandung, Medan, Batam
Harga dagang sesuai penawaran — balasan dalam 24 jam
Jumlah
WhatsApp seorang insinyur
Tidak perlu akun — permintaan penawaran Anda langsung masuk ke tim insinyur kami. Akun gratis memungkinkan Anda melacak penawaran dan memesan ulang lebih cepat.
Pengiriman ke Seluruh Dunia
Pengiriman udara & laut
Lembar Data Atas Permintaan
Spesifikasi teknis
Penawaran 1 Hari
Balasan dalam 24 jam

Spesifikasi Teknis

CRYDOM
Manufacturer Part Number
CKM0630
Type
MOSFET, DC Output
Finger Safe
Yes
Current Type
DC
Input Current
11 mA at 32V DC
Mounting Style
DIN Rail & Panel
Output Voltage
0 to 60V DC
Max Output Current
30 A
Switch Configuration
Form A
Voltage/Current Type
DC Output
Electrical Connection
Screw Clamp
Maximum Output Current without Heat Sink
30 A
Lihat Lembar Spesifikasi Lengkap

Dokumen Teknis

Tidak ada dokumen teknis yang tersedia untuk produk ini.
Minta dokumentasi →
Tidak yakin ini adalah suku cadang yang tepat? Minta rekomendasi.

Butuh bantuan pemasangan atau rekayasa?

Instalasi, komisioning, rencana pemeliharaan, desain sistem, dan penawaran produk + layanan bundel — satu tim menangani cakupan penuh.
Bicaralah dengan seorang insinyur

Ajukan pertanyaan

CRYDOM Produk
3G Electric (S) Pte. Ltd. — Singapore

Deskripsi Produk

The CRYDOM Solid State Relay (MPN CKM0630) is a combination DIN-rail and surface-mounted relay with a DC output. It features a Form A switch configuration, an output voltage range of 0 to 60V DC, and a maximum output current of 30 A without a heat sink. The relay accepts an input current of 11 mA at 32V DC, uses a screw clamp electrical connection, and is finger safe.

Digunakan dalam

Aplikasi umum untuk CRYDOM
Industrial burner control — CRYDOM CL240A10C SSR for modulating gas valve actuation
Pump motor switching — CRYDOM C53TP25CH-10 SSR for single-phase AC motor start/stop
Process heating — CRYDOM EL240A10R-05 SSR for electric heater bank control
DIN-rail thermal management — CRYDOM HS151DR heat sink with fan for SSR cooling in control panels
Three-phase load switching — CRYDOM CD2450W2V dual SSR for two-phase control in industrial ovens

CRYDOM Produk

3G Electric memasok CRYDOM combination din-rail & surface-mounted relays. Kami menyediakan produk asli dengan ketersediaan tersedia di gudang untuk SKU umum, dokumentasi teknis, dukungan commissioning, dan layanan garansi — di seluruh dunia.
