EATON Supplementary Protector: 13 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ - D-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATOND-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 13 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ

EATON FAZ-D13/1-SP adalah IEC Supplementary Protector tipe D-Curve, 1-Pole, dengan rating arus 13 A yang dirancang untuk pemasangan rel DIN. Pelindung tambahan ini memiliki tegangan AC 277/480V dan DC 48V, serta…

SKU 3G-OTH-20096

Merek
EATON
Item
Supplementary Protector: 13 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ
Kategori
D-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Tersedia untuk Dipesan
Stok tersedia & bea cukai ditangani
  • 6–10 business days door-to-door; Bea Cukai clearance typically 3–5 business days.
  • Invoicing in IDR or USD. Bank transfer and corporate PO accepted.
  • Dikirim ke: Jakarta, Surabaya, Bandung, Medan, Batam
Harga dagang sesuai penawaran — balasan dalam 24 jam
Jumlah
WhatsApp seorang insinyur
Tidak perlu akun — permintaan penawaran Anda langsung masuk ke tim insinyur kami. Akun gratis memungkinkan Anda melacak penawaran dan memesan ulang lebih cepat.
Pengiriman ke Seluruh Dunia
Pengiriman udara & laut
Lembar Data Atas Permintaan
Spesifikasi teknis
Penawaran 1 Hari
Balasan dalam 24 jam

Spesifikasi Teknis

EATON
Manufacturer Part Number
FAZ-D13/1-SP
Series
FAZ
Type
15kA at 240/415V AC, Lug, FAZ, D
AC
277/480V
DC
48V
Curve Type
D
Max. AIR Rating
15kA at 240/415V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
48V DC
Terminal Connection
Lug
Lihat Lembar Spesifikasi Lengkap

Dokumen Teknis

Tidak ada dokumen teknis yang tersedia untuk produk ini.
Minta dokumentasi →
Tidak yakin ini adalah suku cadang yang tepat? Minta rekomendasi.

Butuh bantuan pemasangan atau rekayasa?

Instalasi, komisioning, rencana pemeliharaan, desain sistem, dan penawaran produk + layanan bundel — satu tim menangani cakupan penuh.
Bicaralah dengan seorang insinyur

Ajukan pertanyaan

EATON Produk
3G Electric (S) Pte. Ltd. — Singapore

Deskripsi Produk

EATON FAZ-D13/1-SP adalah IEC Supplementary Protector tipe D-Curve, 1-Pole, dengan rating arus 13 A yang dirancang untuk pemasangan rel DIN. Pelindung tambahan ini memiliki tegangan AC 277/480V dan DC 48V, serta kemampuan pemutusan maksimal 15kA pada 240/415V AC. Dengan koneksi terminal lug, produk ini ideal untuk aplikasi proteksi sirkuit tambahan di peralatan industri dan panel kontrol, termasuk sebagai komponen dalam sistem pembakar industri.

Supplied to Indonesia — compatible with 50 Hz installations. DHL Express delivery to Jakarta, Surabaya, Bandung, customs and duties handled door-to-door.

Pertanyaan yang Sering Diajukan

Apa fungsi EATON FAZ-D13/1-SP?

EATON FAZ-D13/1-SP berfungsi sebagai pelindung tambahan (supplementary protector) untuk sirkuit listrik. Produk ini melindungi peralatan dari arus lebih dan hubung singkat, dengan kurva D yang cocok untuk beban induktif seperti motor dan transformator. Rating arusnya 13 A dengan tegangan AC 277/480V dan DC 48V.

Apa spesifikasi teknis EATON FAZ-D13/1-SP?

Spesifikasi teknis EATON FAZ-D13/1-SP meliputi: tipe D-Curve, 1-Pole, arus 13 A, tegangan AC 277/480V, tegangan DC 48V, kemampuan pemutusan maksimal 15kA pada 240/415V AC, koneksi terminal lug, dan pemasangan rel DIN. Produk ini memenuhi standar UL1077.

Di mana beli EATON FAZ-D13/1-SP di Indonesia?

Anda dapat membeli EATON FAZ-D13/1-SP melalui 3G Electric, distributor resmi yang memasok dan mengirimkan produk ini ke seluruh Indonesia. Kami menangani logistik dan bea cukai untuk memastikan produk sampai ke lokasi Anda. Hubungi kami untuk minta penawaran.

Apa perbedaan kurva D pada EATON FAZ-D13/1-SP?

Kurva D pada EATON FAZ-D13/1-SP dirancang untuk menangani lonjakan arus tinggi sementara, seperti pada motor, transformator, atau beban induktif lainnya. Kurva ini memiliki karakteristik trip yang lebih lambat dibanding kurva B atau C, sehingga cocok untuk aplikasi industri dengan arus start tinggi.

Bagaimana cara memasang EATON FAZ-D13/1-SP?

EATON FAZ-D13/1-SP dipasang pada rel DIN standar di panel listrik. Pastikan sirkuit dalam keadaan mati, kemudian klik unit ke rel DIN. Hubungkan kabel ke terminal lug sesuai diagram pengkabelan. Periksa kekencangan sambungan dan pastikan rating arus sesuai dengan beban yang dilindungi.

Digunakan dalam

Aplikasi umum untuk EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas

EATON Produk

3G Electric memasok EATON d-curve, 1-pole ul1077 din rail-mount supplementary protectors. Kami menyediakan produk asli dengan ketersediaan tersedia di gudang untuk SKU umum, dokumentasi teknis, dukungan commissioning, dan layanan garansi — di seluruh dunia.
