SCHNEIDER Selector Switch: 22 mm Panel Mounting Size, 2 Positions, Short Lever, 1NO/1NC - Illuminated Selector Switches
SCHNEIDERIlluminated Selector Switches

SCHNEIDER Selector Switch: 22 mm Panel Mounting Size, 2 Positions, Short Lever, 1NO/1NC

The SCHNEIDER XB4BK125B5 is an illuminated selector switch from the XB4 series, featuring a 22 mm panel mounting size with a short-handled knob and metallic bezel. It offers a maintained/maintained action across two…

SKU 3G-OTH-34255

Merek
SCHNEIDER
Item
Selector Switch: 22 mm Panel Mounting Size, 2 Positions, Short Lever, 1NO/1NC
Kategori
Illuminated Selector Switches
Tersedia untuk Dipesan
Stok tersedia & bea cukai ditangani
  • 6–10 business days door-to-door; Bea Cukai clearance typically 3–5 business days.
  • Invoicing in IDR or USD. Bank transfer and corporate PO accepted.
  • Dikirim ke: Jakarta, Surabaya, Bandung, Medan, Batam
Harga dagang sesuai penawaran — balasan dalam 24 jam
Jumlah
WhatsApp seorang insinyur
Tidak perlu akun — permintaan penawaran Anda langsung masuk ke tim insinyur kami. Akun gratis memungkinkan Anda melacak penawaran dan memesan ulang lebih cepat.
Pengiriman ke Seluruh Dunia
Pengiriman udara & laut
Lembar Data Atas Permintaan
Spesifikasi teknis
Penawaran 1 Hari
Balasan dalam 24 jam

Spesifikasi Teknis

SCHNEIDER
Manufacturer Part Number
XB4BK125B5
Series
XB4
Type
Short Lever, 1NO/1NC, Metallic
Cam
No Cam Included
Action
Maintained/Maintained
Positions
2
AC Contact Rating
6 A @ 120 V
DC Contact Rating
0.1 A @ 600 V
Operator Head Type
Short-Handled Knob
Operator Illumination
Illuminated
Operator Head Material
Plastic
Switch Bezel Material Type
Metallic
Switch Function @ 1st Position
Off
Switch Function @ 2nd Position
On
Switch Function @ 3rd Position
No Third Position
Switch Function @ 4th Position
No Fourth Position
Hazardous Location Specification
Not Rated
Lihat Lembar Spesifikasi Lengkap

Dokumen Teknis

Tidak ada dokumen teknis yang tersedia untuk produk ini.
Minta dokumentasi →
Tidak yakin ini adalah suku cadang yang tepat? Minta rekomendasi.

Butuh bantuan pemasangan atau rekayasa?

Instalasi, komisioning, rencana pemeliharaan, desain sistem, dan penawaran produk + layanan bundel — satu tim menangani cakupan penuh.
Bicaralah dengan seorang insinyur

Ajukan pertanyaan

SCHNEIDER Produk
3G Electric (S) Pte. Ltd. — Singapore

Deskripsi Produk

The SCHNEIDER XB4BK125B5 is an illuminated selector switch from the XB4 series, featuring a 22 mm panel mounting size with a short-handled knob and metallic bezel. It offers a maintained/maintained action across two positions (Off/On) and is rated for 6 A at 120 V AC and 0.1 A at 600 V DC. The plastic operator head is illuminated, and no cam is included.

Supplied to Indonesia — compatible with 50 Hz installations. DHL Express delivery to Jakarta, Surabaya, Bandung, customs and duties handled door-to-door.

Pertanyaan yang Sering Diajukan

What is the SCHNEIDER XB4BK125B5 selector switch used for?

The SCHNEIDER XB4BK125B5 illuminated selector switch is used for manual on/off control in industrial control panels, machinery, and automation systems. Its maintained/maintained action keeps the selected position until manually changed, making it suitable for start/stop or mode selection in manufacturing, HVAC, and process control applications.

What are the specifications of the SCHNEIDER XB4BK125B5?

The SCHNEIDER XB4BK125B5 is a 22 mm panel-mount illuminated selector switch with a short-handled knob and metallic bezel. It has 2 positions (Off/On) with maintained/maintained action, AC contact rating of 6 A at 120 V, DC contact rating of 0.1 A at 600 V, and a plastic operator head. No cam is included.

Where to buy the SCHNEIDER XB4BK125B5 worldwide?

3G Electric supplies the SCHNEIDER XB4BK125B5 illuminated selector switch worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this genuine SCHNEIDER part.

How to install the SCHNEIDER XB4BK125B5 selector switch?

Install the SCHNEIDER XB4BK125B5 by mounting it in a 22 mm panel cutout, securing with the provided nut. Wire the 1NO/1NC contacts according to your control circuit, ensuring voltage and current do not exceed 6 A at 120 V AC or 0.1 A at 600 V DC. Follow standard industrial wiring practices for safety.
