Aaon 3G-OTH-68549 — Spesifikasi Teknis
The AAON Damper Actuator (SKU 408WH9, MPN P82300) is a fail-safe spring-return actuator with a 90° stroke and CCW shaft rotation. It operates on 24V input with a 5W power rating and a 0 to 10V DC output signal, featuring self-centering shaft and quick-connect terminals. This actuator is not plenum rated and is not compatible with building automation systems.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Type | Floating Point, Spring Return, 25 in-lb, 24V, Quick Connect Terminals |
| Brand | AAON |
| Shaft Type | Self-Centering |
| Power Rating | 5W |
| Input Voltage | 24V |
| Output Signal | 0 to 10V DC |
| Plenum Rating | Not Plenum Rated |
| Stroke Degree | 90° |
| Shaft Rotation | CCW |
| Manufacturer Part Number | P82300 |
| Auxiliary Switch Included | No |
| Electrical Connection Type | Quick Connect Terminals |
| For Use With Building Automation Systems | Not Building Automation System Compatible |
