Ashcroft 3G-OTH-176428 — Spesifikasi Teknis
The ASHCROFT A4 Series General Industrial Pressure Transducer is a pressure transmitter with cable and wire leads, offering a 0 psi to 200 psi range and a 4 to 20mA DC output. It features ±0.25% accuracy, a stainless steel housing, IP65 and NEMA 4X ratings, and a 1/4 in Male NPT process connection. The transducer includes a NIST-Traceable Calibration Certificate and has an overpressure of 1.5x range and burst pressure of 2x range.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| DC | 4 to 20mA |
| Type | Cable |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | A4 |
| Accuracy | ±0.25% |
| Male NPT | 1/4 in |
| IP Rating | IP65 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| Burst Pressure | 2x Range |
| Housing Material | Stainless Steel |
| Electrical Connections | Cable |
| Process Connection Type | NPT |
| Manufacturer Part Number | A4SAM0242F2200#G |
| Process Connection Gender | Male |
| Calibration Certificate Included | NIST-Traceable Calibration Certificate Included |
