Barnes & Jones 3G-OTH-71393 — Spesifikasi Teknis
The BARNES & JONES Steam Trap is a Cast Iron H-Pattern Float & Thermostatic Steam Trap, model FT2015-4 (SKU 845KE3). It features a 1 in FNPT connection, a capacity of 1,129 lb/hr, a maximum pressure of 15 psig, and a maximum temperature of 345°F. The trap is designed for horizontal installation and includes a stainless steel float, part of Manufacturer Series A.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| FNPT | 1 in |
| Max. | 345°F |
| Type | 1,129 lb/hr, 15 psig Max., H Pattern |
| Brand | BARNES & JONES |
| Float Material | Stainless Steel |
| Manufacturer Series | A |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | FT2015-4 |
