Chainflex 3G-OTH-52404 — Spesifikasi Teknis

Name: Chainflex 3G-OTH-52404 CHAINFLEX Control Cable: 17 AWG, 3 Conductors, Order by the Foot, PVC Jacket, 300 V (MPN CF140-10-03). Key specifications — Conductor Material: Copper; Conductor Configuration: Single; Minimum Bend Radius Factor - Fixed: 4 x OD; Minimum Bend Radius Factor - Flexible: 6 x OD; Includes Ground: Yes; Minimum Bend Radius Factor - E-Chain: 7.5 x OD; Resistance Properties: Oil and Grease Resistant; Standards: FT-2.
Brand: Chainflex

The CHAINFLEX Control Cable: 17 AWG (SKU 801JA0) is a continuous flexing control cable from the Chainflex CF140-UL series. This 3-conductor, single-conductor-configuration cable features a copper conductor, PVC jacket, and includes a ground, rated at 300 V. It is oil and grease resistant, meets FT-2 standards, and has minimum bend radius factors of 4 x OD (fixed), 6 x OD (flexible), and 7.5 x OD (e-chain).

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	Order by the Foot, PVC Jacket, 300 V
Brand	CHAINFLEX
Series	Chainflex
Standards	FT-2
Conductors	3
Cable Series	CF140-UL
Product Type	Control Cable
Includes Ground	Yes
Conductor Material	Copper
Resistance Properties	Oil and Grease Resistant
Conductor Configuration	Single
Manufacturer Part Number	CF140-10-03
Minimum Bend Radius Factor - Fixed	4 x OD
Minimum Bend Radius Factor - E-Chain	7.5 x OD
Minimum Bend Radius Factor - Flexible	6 x OD
