Chainflex 3G-OTH-51566 — Spesifikasi Teknis

Name: Chainflex 3G-OTH-51566 CHAINFLEX Control Cable: 20 AWG, 3 Conductors, Order by the Foot, PVC Jacket, 300 V (MPN CF880-05-03). Key specifications — Conductor Material: Copper; Conductor Configuration: Single; Minimum Bend Radius Factor - Fixed: 7 x OD; Minimum Bend Radius Factor - Flexible: 10 x OD; Includes Ground: Yes; Minimum Bend Radius Factor - E-Chain: 12.5 x OD; Resistance Properties: Oil and Grease Resistant; Standards: IEC 60332-1-2.
Brand: Chainflex

The CHAINFLEX Control Cable: 20 AWG (SKU 801JY3, MPN CF880-05-03) is a continuous flexing control cable from the Chainflex CF880 series. It features 3 conductors of single copper wire with a PVC jacket, rated 300 V, and includes a ground conductor. The cable is oil and grease resistant, complies with IEC 60332-1-2, and has minimum bend radius factors of 7 x OD (fixed), 10 x OD (flexible), and 12.5 x OD (e-chain).

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	Order by the Foot, PVC Jacket, 300 V
Brand	CHAINFLEX
Series	Chainflex
Standards	IEC 60332-1-2
Conductors	3
Cable Series	CF880
Product Type	Control Cable
Includes Ground	Yes
Conductor Material	Copper
Resistance Properties	Oil and Grease Resistant
Conductor Configuration	Single
Manufacturer Part Number	CF880-05-03
Minimum Bend Radius Factor - Fixed	7 x OD
Minimum Bend Radius Factor - E-Chain	12.5 x OD
Minimum Bend Radius Factor - Flexible	10 x OD
