Chainflex 3G-OTH-47089 — Spesifikasi Teknis

Name: Chainflex 3G-OTH-47089 CHAINFLEX Motor Cable: 4 AWG, 1 Conductors, Order by the Foot, PVC Jacket, 600 V (MPN CF885-40-01). Key specifications — Conductor Material: Copper; Conductor Configuration: Single; Minimum Bend Radius Factor - Fixed: 8 x OD; Minimum Bend Radius Factor - Flexible: 12 x OD; Includes Ground: No; Minimum Bend Radius Factor - E-Chain: 15 x OD; Resistance Properties: Flame Retardant; Standards: IEC 60332-1-2.
Brand: Chainflex

The CHAINFLEX CF885-40-01 is a continuous flexing power cable from the Chainflex series, designed as a single-conductor motor cable with 4 AWG copper wire and a PVC jacket rated for 600 V. It features a single conductor configuration without an included ground, and offers minimum bend radius factors of 8 x OD for fixed installation, 12 x OD for flexible use, and 15 x OD for e-chain applications. This cable is flame retardant per IEC 60332-1-2 and is sold by the foot.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Brand	CHAINFLEX
Series	Chainflex
Standards	IEC 60332-1-2
Cable Series	CF885
Product Type	Motor Cable
Includes Ground	No
Conductor Material	Copper
Resistance Properties	Flame Retardant
Conductor Configuration	Single
Manufacturer Part Number	CF885-40-01
Minimum Bend Radius Factor - Fixed	8 x OD
Minimum Bend Radius Factor - E-Chain	15 x OD
Minimum Bend Radius Factor - Flexible	12 x OD
