Chainflex 3G-OTH-46599 — Spesifikasi Teknis

Name: Chainflex 3G-OTH-46599 CHAINFLEX Motor Cable: 6 AWG, 4 Conductors, Order by the Foot, PUR Jacket, 1,000 V (MPN CF895-160-04). Key specifications — Conductor Material: Copper; Conductor Configuration: Single; Minimum Bend Radius Factor - Fixed: 8 x OD; Minimum Bend Radius Factor - Flexible: 12 x OD; Includes Ground: Yes; Minimum Bend Radius Factor - E-Chain: 15 x OD; Resistance Properties: UV/Sunlight Resistant; Standards: EAC TC RU C-DE. ME77.B.01561.
Brand: Chainflex

The CHAINFLEX Motor Cable: 6 AWG is a continuous flexing power cable from the Chainflex series, model CF895-160-04, featuring 4 conductors with a copper conductor material and a PUR jacket rated for 1,000 V. It includes a ground conductor and offers UV/sunlight resistance, with minimum bend radius factors of 8 x OD for fixed installation, 12 x OD for flexible use, and 15 x OD for e-chain applications. This cable complies with EAC TC RU C-DE. ME77.B.01561 standards.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	Order by the Foot, PUR Jacket, 1,000 V
Brand	CHAINFLEX
Series	Chainflex
Standards	EAC TC RU C-DE. ME77.B.01561
Conductors	4
Cable Series	CF895
Product Type	Motor Cable
Includes Ground	Yes
Conductor Material	Copper
Resistance Properties	UV/Sunlight Resistant
Conductor Configuration	Single
Manufacturer Part Number	CF895-160-04
Minimum Bend Radius Factor - Fixed	8 x OD
Minimum Bend Radius Factor - E-Chain	15 x OD
Minimum Bend Radius Factor - Flexible	12 x OD
