Crydom 3G-OTH-37714 — Spesifikasi Teknis

Name: Crydom 3G-OTH-37714 CRYDOM Solid State Relay: Surface Mounted, 90 A Max Output Current, SCR, AC Output (MPN D2490). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 12 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel; Output Voltage: 24 to 280V AC.
Brand: Crydom

The CRYDOM D2490 is a panel-mounted solid-state relay with an AC output, rated for 24 to 280V AC and 90 A max output current. It features a Form A (SPST-NO) switch configuration, screw-clamp electrical connection, and 12 mA input current. This relay is not finger-safe and is not recommended for use without a heat sink.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	12 mA
Mounting Style	Panel
Output Voltage	24 to 280V AC
Max Output Current	90 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	D2490
Maximum Output Current Without Heat Sink	Not Recommended
