Crydom 3G-OTH-38143 — Spesifikasi Teknis

Name: Crydom 3G-OTH-38143 CRYDOM Solid State Relay: Surface Mounted, 12 A Max Output Current, SCR, AC Output (MPN HD4812). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 12 mA; Maximum Output Current without Heat Sink: 10 A; Mounting Style: Panel; Output Voltage: 48 to 530V AC.
Brand: Crydom

The CRYDOM Solid State Relay (MPN HD4812) is a panel-mounted, AC-output relay with a Form A switch configuration. It features an output voltage range of 48 to 530V AC, a maximum output current without heat sink of 10 A, and an input current of 12 mA. The relay uses a screw clamp electrical connection and is not finger-safe.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	12 mA
Mounting Style	Panel
Output Voltage	48 to 530V AC
Max Output Current	12 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	HD4812
Maximum Output Current Without Heat Sink	10 A
