Crydom 3G-OTH-38202 — Spesifikasi Teknis

Name: Crydom 3G-OTH-38202 CRYDOM Solid State Relay: Surface Mounted, 25 A Max Output Current, SCR, AC Output (MPN HD4825). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 12 mA; Maximum Output Current without Heat Sink: 12 A; Mounting Style: Panel; Output Voltage: 48 to 530V AC.
Brand: Crydom

The CRYDOM HD4825 is a panel-mounted solid-state relay with an AC output, featuring a Form A (SPST-NO) switch configuration and screw-clamp electrical connections. It operates with an input current of 12 mA and an output voltage range of 48 to 530V AC. The maximum output current without a heat sink is 12 A, and the relay is not finger-safe.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	12 mA
Mounting Style	Panel
Output Voltage	48 to 530V AC
Max Output Current	25 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	HD4825
Maximum Output Current Without Heat Sink	12 A
