Crydom 3G-OTH-39063 — Spesifikasi Teknis

Name: Crydom 3G-OTH-39063 CRYDOM Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR, AC Output (MPN A2450E). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 10 mA; Input Voltage: 18-36 VAC; Maximum Output Current without Heat Sink: 11 A; Mounting Style: Panel.
Brand: Crydom

The CRYDOM A2450E is a panel-mounted solid-state relay with a Form A (SPST-NO) SCR output for AC loads. It accepts an 18-36 VAC control input drawing 10 mA and switches 24 to 280V AC, with a maximum output current of 11 A without a heat sink. Electrical connections are made via screw clamps.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	10 mA
Input Voltage	18-36 VAC
Mounting Style	Panel
Output Voltage	24 to 280V AC
Max Output Current	50 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	A2450E
Maximum Output Current Without Heat Sink	11 A
