Crydom 3G-OTH-40413 — Spesifikasi Teknis

Name: Crydom 3G-OTH-40413 CRYDOM Solid State Relay: Surface Mounted, 25 A Max Output Current, SCR, AC Output (MPN HA4825E). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 10 mA; Input Voltage: 18-36 VAC; Maximum Output Current without Heat Sink: 12 A; Mounting Style: Panel.
Brand: Crydom

The CRYDOM Solid State Relay is a panel-mounted, AC-output relay with a Form A (SPST-NO) switch configuration. It accepts an 18-36 VAC input at 10 mA and switches 48 to 530V AC output, with a maximum output current of 12 A without a heat sink. The relay uses a screw-clamp electrical connection and is not finger-safe.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	10 mA
Input Voltage	18-36 VAC
Mounting Style	Panel
Output Voltage	48 to 530V AC
Max Output Current	25 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	HA4825E
Maximum Output Current Without Heat Sink	12 A
