Crydom 3G-OTH-36651 — Spesifikasi Teknis

Name: Crydom 3G-OTH-36651 CRYDOM Solid State Relay: DIN-Rail Mounted, 10 A Max Output Current, SCR, AC Output (MPN CKRD2410). Key specifications — Brand: CRYDOM; Current Type: DC; Electrical Connection: Box Clamp; Finger Safe: Yes; Input Current: 8 to 12 mA; Maximum Output Current without Heat Sink: 10 A; Mounting Style: DIN Rail; Output Voltage: 24 to 280V AC.
Brand: Crydom

The CRYDOM CKRD2410 is a DIN-Rail Mounted Solid State Relay with an AC output, featuring a Form A (SCR) switch configuration. It operates with a DC input current of 8 to 12 mA and provides an output voltage range of 24 to 280V AC, with a maximum output current of 10 A without a heat sink. This finger-safe relay uses a box clamp electrical connection and is designed for DIN-rail mounting.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	Yes
Current Type	DC
Input Current	8 to 12 mA
Mounting Style	DIN Rail
Output Voltage	24 to 280V AC
Max Output Current	10 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Box Clamp
Manufacturer Part Number	CKRD2410
Maximum Output Current Without Heat Sink	10 A
