Crydom 3G-OTH-36725 — Spesifikasi Teknis

Name: Crydom 3G-OTH-36725 CRYDOM Solid State Relay: DIN-Rail Mounted, 30 A Max Output Current, SCR, AC Output (MPN CKRD4830-10). Key specifications — Brand: CRYDOM; Current Type: DC; Electrical Connection: Screw Clamp; Finger Safe: Yes; Input Current: 8 to 12 mA; Maximum Output Current without Heat Sink: 30 A; Mounting Style: DIN Rail; Output Voltage: 48 to 530V AC.
Brand: Crydom

The CRYDOM Solid State Relay is a DIN-Rail Mounted relay with a maximum output current of 30 A without a heat sink and an output voltage range of 48 to 530V AC. It features a DC input current of 8 to 12 mA, a Form A (SPST-NO) switch configuration, and a screw clamp electrical connection. This AC-output relay is finger-safe and designed for DIN-rail mounting.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	Yes
Current Type	DC
Input Current	8 to 12 mA
Mounting Style	DIN Rail
Output Voltage	48 to 530V AC
Max Output Current	30 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	CKRD4830-10
Maximum Output Current Without Heat Sink	30 A
