Crydom 3G-OTH-37979 — Spesifikasi Teknis

Name: Crydom 3G-OTH-37979 CRYDOM Dual Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR, AC Output (MPN CC2450W3V). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: Yes; Input Current: 10 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel; Output Voltage: 24 to 280V AC.
Brand: Crydom

The CRYDOM Dual Solid State Relay is a panel-mounted, AC-output relay with a Form A switch configuration and a maximum output current of 50 A. It features a screw-clamp electrical connection, an input current of 10 mA, and an output voltage range of 24 to 280V AC. The relay is finger-safe and uses SCR technology, though operation without a heat sink is not recommended.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	Yes
Current Type	AC
Input Current	10 mA
Mounting Style	Panel
Output Voltage	24 to 280V AC
Max Output Current	50 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	CC2450W3V
Maximum Output Current Without Heat Sink	Not Recommended
