Crydom 3G-OTH-39673 — Spesifikasi Teknis

Name: Crydom 3G-OTH-39673 CRYDOM Dual Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR, AC Output (MPN CD2450W2V). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 10 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel; Output Voltage: 24 to 280V AC.
Brand: Crydom

The CRYDOM Dual Solid State Relay is a panel-mounted, AC-output relay with a Form A switch configuration and screw-clamp electrical connection. It operates with an input current of 10 mA and an output voltage range of 24 to 280V AC. The relay is not finger-safe and is not recommended for use without a heat sink.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	10 mA
Mounting Style	Panel
Output Voltage	24 to 280V AC
Max Output Current	50 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	CD2450W2V
Maximum Output Current Without Heat Sink	Not Recommended
