Crydom 3G-OTH-40330 — Spesifikasi Teknis

Name: Crydom 3G-OTH-40330 CRYDOM Solid State Relay: Surface Mounted, 25 A Max Output Current, SCR, AC Output (MPN D53TP25CH-10). Key specifications — Brand: CRYDOM; Current Type: DC; Electrical Connection: Saddle Clamp; Screw; Finger Safe: Yes; Input Current: 35 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel.
Brand: Crydom

The CRYDOM Solid State Relay is a panel-mounted, surface-mounted relay with a DC input current of 35 mA and an AC output voltage range of 48 to 530V AC. It features a Form A switch configuration, SCR output, and a saddle-clamp electrical connection, with a maximum output current of 25 A (operation without a heat sink is not recommended). This finger-safe relay is designed for AC output applications.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	Yes
Current Type	DC
Input Current	35 mA
Mounting Style	Panel
Output Voltage	48 to 530V AC
Max Output Current	25 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Saddle Clamp
Manufacturer Part Number	D53TP25CH-10
Maximum Output Current Without Heat Sink	Not Recommended
