Dwyer 3G-OTH-29203 — Spesifikasi Teknis

Name: Dwyer 3G-OTH-29203 DWYER Analog Panel Meter: 999,999 Display Span - Max, 85 V AC – 265 V AC, 0.6 in Digit Ht - Max., 4X (MPN APM-120). Key specifications — Manufacturer Part Number: APM-120; Accuracy: +/-0.03%; Digital Display Screen Color: Red; Digital Display Screen Type: LED; Includes: USB Based Programming Software is Resident on the Meter; NEMA Enclosure Rating: 4X; Product Type: ANot Applicablelog Panel Meter; Series: APM.
Brand: Dwyer

The Dwyer APM Series Analog Panel Meter is an AC current digital panel meter with a 999,999 display span. It features a red LED display, +/-0.03% accuracy, and a NEMA 4X enclosure rating. The meter includes USB-based programming software and offers SPST relay contacts rated at 3A @ 30 VDC and 125/250 VAC, with screw clamp terminal connections.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	- Max, 85 V AC – 265 V AC, 0.6 in Digit Ht - Max., 4X
Brand	DWYER
Series	APM
Accuracy	+/-0.03%
Includes	USB Based Programming Software is Resident on the Meter
Interface	USB
Input Type	AC Current
Product Type	ANot Applicablelog Panel Meter
Relay Contact Form	SPST
NEMA Enclosure Rating	4X
Relay AC Contact Rating	3A @ 30 VDC and 125/250 VAC
Relay DC Contact Rating	3A @ 30 VDC and 125/250 VAC
Manufacturer Part Number	APM-120
Terminal Connection Type	Screw Clamp
Digital Display Screen Type	LED
Digital Display Screen Color	Red
