Eaton 3G-OTH-22604 — Spesifikasi Teknis

Name: Eaton 3G-OTH-22604 EATON Surge Protection Device: Single Phase, 120V AC, 1 Poles, 2 + Ground Wires, L-G/L-N/N-G, 5kA (MPN AGPH12015). Key specifications — Voltage: 120V AC; Number of Wires: 2 Wires + Ground; Modes of Protection: L-G; Max. Continuing Operating Voltage: 150 V AC; Voltage Protection Rating: 330V (L-G, N-G); Short Circuit Current Rating: 5kA; Filtering: Yes; Enclosure Material: Polycarbonate.
Brand: Eaton

The EATON Surge Protection Device (SKU 30UJ05) is a single-phase, DIN Rail internal-mount SPD with a 120V AC rating, 2 wires plus ground, and L-G mode of protection. It features a Voltage Protection Rating of 330V (L-G, N-G), a Short Circuit Current Rating of 5kA, and a Max. Continuing Operating Voltage of 150 V AC, housed in a polycarbonate enclosure with filtering capability.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
AC	120V
Type	2 + Ground Wires, L-G/L-N/N-G, 5kA
Brand	EATON
Poles	1
Voltage	120V AC
Filtering	Yes
Mounting Style	DIN-Rail
Number Of Wires	2 Wires + Ground
Enclosure Material	Polycarbonate
Modes Of Protection	L-G
Manufacturer Part Number	AGPH12015
Voltage Protection Rating	330V (L-G, N-G)
Short Circuit Current Rating	5kA
Max. Continuing Operating Voltage	150 V AC
