Eaton 3G-OTH-36482 — Spesifikasi Teknis

Name: Eaton 3G-OTH-36482 EATON Selector Switch: 30 mm Panel Mounting Size, 2 Positions, Short Lever, 1NO/1NC, Metallic (MPN 10250T20KB). Key specifications — AC Contact Rating: 10 A @ 600 V; Action: Maintained/Maintained; Cam: 3; DC Contact Rating: 5 A @ 250 V; Hazardous Location Specification: Not Rated; Operator Head Material: Polymer; Operator Head Type: Short-Handled Knob; Operator Illumination: Non-Illuminated.
Brand: Eaton

The EATON 10250T20KB is a 30 mm panel-mounting selector switch from the 10250T Series, featuring a short-handled knob operator head with a maintained/maintained action and a metallic bezel. It offers two positions with On/On switching functions, a Cam 3 configuration, and is rated for AC contact at 10 A @ 600 V and DC contact at 5 A @ 250 V. The non-illuminated polymer operator head and absence of hazardous location rating define its standard industrial application.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Cam	3
Type	Short Lever, 1NO/1NC, Metallic
Brand	EATON
Action	Maintained/Maintained
Series	10250T
Positions	2
AC Contact Rating	10 A @ 600 V
DC Contact Rating	5 A @ 250 V
Operator Head Type	Short-Handled Knob
Operator Illumination	Non-Illuminated
Operator Head Material	Polymer
Manufacturer Part Number	10250T20KB
Switch Bezel Material Type	Metallic
Switch Function @ 1st Position	On
Switch Function @ 2nd Position	On
Switch Function @ 3rd Position	No Third Position
Switch Function @ 4th Position	No Fourth Position
Hazardous Location Specification	Not Rated
