Eaton 3G-OTH-23675 — Spesifikasi Teknis

Name: Eaton 3G-OTH-23675 EATON Molded Case Circuit Breaker: 50 A Amps, 65kA at 600V AC, Fixed, ABC, Line/Load Lug, Std, HMCP (MPN HMCPE050K2C). Key specifications — Series: HMCP; Max. AIR Rating: 65kA at 600V AC; Instantaneous Trip: Fixed; Phase Connection: ABC; Terminal Connection: Line/Load Lug; Frame Size: 125A/EG.
Brand: Eaton

The EATON HMCPE050K2C is a 50 A molded case circuit breaker from the HMCP series of motor circuit protectors. It features a 125A/EG frame size, a maximum AIR rating of 65kA at 600V AC, and a fixed instantaneous trip. This unit uses ABC phase connection and line/load lug terminals.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	65kA at 600V AC, Fixed, ABC, Line/Load Lug, Std, HMCP
Series	HMCP
Frame Size	125A/EG
Max. AIR Rating	65kA at 600V AC
Phase Connection	ABC
Instantaneous Trip	Fixed
Terminal Connection	Line/Load Lug
Manufacturer Part Number	HMCPE050K2C
