Ezo 3G-OTH-108701 — Spesifikasi Teknis
The EZO F4-9M is a separable grooved-race ball thrust bearing from the FM Series, featuring a 4 mm bore diameter, 9 mm outside diameter, and 4 mm overall width. It is constructed with SUJ2 steel balls and is rated for a maximum speed of 22,000 RPM with oil lubrication. This metric bearing is identified by industry number F4-9M.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Type | Grooved, Steel |
| Brand | EZO |
| Bore Dia | 4 mm |
| Overall Wd | 4 mm |
| Outside Dia | 9 mm |
| Maximum Speed | 22,000 RPM Oil |
| Bearing Series | FM Series |
| Ball Material Grade | SUJ2 |
| Thrust Bearing Type | Separable Ball Thrust Bearing |
| System Of Measurement | Metric |
| Bearing Industry Number | F4-9M |
| Manufacturer Part Number | F4-9M |
