Gems Sensors 3G-OTH-89411 — Spesifikasi Teknis
The GEMS SENSORS Air Flow Switch: Piston is an adjustable set point flow switch with a normally closed switch position and a 20 V DC contact rating. It is constructed with 316 stainless steel, features a 1/2 in FNPT connection, and is certified for hazardous locations per Class I, Div 2, Groups A, B, C, D. This product is available under manufacturer part numbers FS-10798 and 25366.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| FNPT | 1/2 in |
| Type | FNPT |
| Brand | GEMS SENSORS |
| Set Point Type | Adjustable |
| Connection Size | 1/2 in |
| Stainless Steel | 316 |
| Switch Position | Normally Closed |
| Contact Rating (DC) | 20 V |
| Manufacturer Part Number | FS-10798, 25366 |
| Hazardous Location Specification | Class I, Div 2, Group A, B, C, D |
