Harris 3G-OTH-358193 — Spesifikasi Teknis

Name: Harris 3G-OTH-358193 HARRIS Gas Regulator: Single Stage, CGA 346 Inlet, 9/16"-18 M RH Outlet, 200 psig, Breathing Air (MPN 425-200-346). Key specifications — Brand: HARRIS; Manufacturer Part Number: 425-200-346; Diaphragm Material: Neoprene; Outlet Connection: 9/16"-18 M RH; Inlet Connection: CGA 346.
Brand: Harris

The HARRIS Gas Regulator is a single-stage air and inert gas regulator with a CGA 346 inlet connection and a 9/16"-18 M RH outlet connection. It features a neoprene diaphragm and is designed for breathing air applications up to 200 psig. This model, part number 425-200-346, is suitable for industrial gas regulation.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	CGA 346 Inlet, 200 psig, Breathing Air
Brand	HARRIS
RH Outlet	9/16"-18 M
Inlet Connection	CGA 346
Outlet Connection	9/16"-18 M RH
Diaphragm Material	Neoprene
Manufacturer Part Number	425-200-346
