Harris 3G-OTH-359380 — Spesifikasi Teknis
The HARRIS Gas Regulator is a single-stage fuel gas regulator designed for acetylene service. It features a 1/4" NPT F inlet and a 9/16"-18 M LH outlet, with a 15 psig delivery pressure and a neoprene diaphragm. This model, MPN 447NC-15-1/4 L, is suitable for controlling gas flow in industrial applications.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Type | 15 psig, Acetylene |
| Brand | HARRIS |
| LH Outlet | 9/16"-18 M |
| NPT F Inlet | 1/4" |
| Inlet Connection | 1/4" NPT F |
| Outlet Connection | 9/16"-18 M LH |
| Diaphragm Material | Neoprene |
| Manufacturer Part Number | 447NC-15-1/4 L |
