Johnson Controls 3G-OTH-67880 — Spesifikasi Teknis
The JOHNSON CONTROLS M9124-JGA-2 is a non-fail-safe actuator for dampers and valves, operating on 24V AC/DC with a 0 to 10V DC output signal. It features a 0 to 90° stroke degree, CW/CCW shaft rotation, and a plug-in electrical connection. This actuator is building automation system compatible and has a torque rating of 210 in-lb.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Type | Floating Point, Non-Spring Return, 210 in-lb, Plug-In |
| AC/DC | 24V |
| Brand | JOHNSON CONTROLS |
| Input Voltage | 24V AC/DC |
| Output Signal | 0 to 10V DC |
| Stroke Degree | 0 to 90° |
| Shaft Rotation | CW/CCW |
| Manufacturer Part Number | M9124-JGA-2 |
| Auxiliary Switch Included | No |
| Electrical Connection Type | Plug-In |
| For Use With Building Automation Systems | Building Automation System Compatible |
