Johnson Controls 3G-OTH-68765 — Spesifikasi Teknis
The JOHNSON CONTROLS HE-69135NS-0 is a duct-mounted temperature and humidity sensor with a plastic housing and no display. It measures relative humidity from 0 to 100% with an accuracy of ±3% of full scale and outputs a 0 to 5V DC signal, while temperature accuracy is ±0.34°F over a 32°F to 131°F range. The sensor connects via screw terminals and is compatible with building automation systems.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Brand | JOHNSON CONTROLS |
| Display | No Display |
| Housing | Plastic |
| Product Type | Duct Temperature and Humidity Sensor |
| Humidity Output | 0 to 5V DC |
| Mounting Location | Duct Mount |
| Temperature Accuracy | ±0.34°F |
| Relative Humidity Range | 0 to 100% |
| Manufacturer Part Number | HE-69135NS-0 |
| Electrical Connection Type | Screw Terminals |
| Relative Humidity Accuracy | ±3% of Full Scale |
| For Use With Building Automation Systems | Building Automation System Compatible |
