Leeson 3G-OTH-78152 — Spesifikasi Teknis

Name: Leeson 3G-OTH-78152 LEESON General Purpose Motor: Rigid Base Mount, Open Drip Proof, 2 hp, 208-230/460V AC, 1,725 RPM (MPN 056T17D3307). Key specifications — Brand: LEESON; Nameplate Voltage @ 60 Hz: 208-230/460V AC; Full Load Current @ 60 Hz: 6.2-6.2/3.1 A; Nameplate RPM @ 60 Hz: 1,725 RPM; Motor Enclosure: ODP.
Brand: Leeson

The LEESON General Purpose Motor: Rigid Base Mount (SKU 44Y994, MPN 056T17D3307) is a 2 hp, rigid base 3-phase AC motor with an ODP enclosure. It operates at 1,725 RPM and accepts 208-230/460V AC input, drawing a full load current of 6.2-6.2/3.1 A at 60 Hz.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
AC	208-230/460V
Type	Open Drip Proof, 2 hp, 1,725 RPM
Brand	LEESON
Motor Enclosure	ODP
Nameplate RPM @ 60 Hz	1,725 RPM
Manufacturer Part Number	056T17D3307
Full Load Current @ 60 Hz	6.2-6.2/3.1 A
Nameplate Voltage @ 60 Hz	208-230/460V AC
