Leeson 3G-OTH-67633 — Spesifikasi Teknis

Name: Leeson 3G-OTH-67633 LEESON General Purpose Motor: Rigid Base Mount, Totally Enclosed Fan Cooled, 3/4 hp, 230/460V AC (MPN 143TTFR5376). Key specifications — Brand: LEESON; Nameplate Voltage @ 60 Hz: 230/460V AC; Full Load Current @ 60 Hz: 3.2-3.2/1.6 A; Nameplate RPM @ 60 Hz: 1,145 RPM; Motor Enclosure: TEFC.
Brand: Leeson

The LEESON General Purpose Motor: Rigid Base Mount (SKU 44Z743) is a rigid base 3-phase general purpose AC motor with a TEFC enclosure. It operates at 1,145 RPM at 60 Hz and 3/4 hp, with a nameplate voltage of 230/460V AC and a full load current of 3.2-3.2/1.6 A at 60 Hz.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
AC	230/460V
Type	Totally Enclosed Fan Cooled, 3/4 hp
Brand	LEESON
Motor Enclosure	TEFC
Nameplate RPM @ 60 Hz	1,145 RPM
Manufacturer Part Number	143TTFR5376
Full Load Current @ 60 Hz	3.2-3.2/1.6 A
Nameplate Voltage @ 60 Hz	230/460V AC
