Mepco 3G-OTH-71300 — Spesifikasi Teknis
The MEPCO Cast Iron H-Pattern Float & Thermostatic Steam Trap (SKU 402W73, MPN 46-775G) is a horizontal-installation steam trap with a stainless steel float. It features a 1 1/2 in FNPT connection, a capacity of 5,000 lb/hr, and maximum ratings of 75 psi and 450°F.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| FNPT | 1 1/2 in |
| Max. | 75 psi |
| Type | 5,000 lb/hr, H Pattern |
| Brand | MEPCO |
| Float Material | Stainless Steel |
| Manufacturer Series | 46 |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | 46-775G |
