Mepco 3G-OTH-70078 — Spesifikasi Teknis
The MEPCO Steam Trap: Cast Iron is a Cast Iron C-Pattern Float & Thermostatic Steam Trap (MPN SA30-9125G) from the Manufacturer Series 30. It features a 2 1/2 in FNPT connection, a capacity of 108,000 lb/hr, and a maximum pressure of 125 psi with a maximum temperature of 450°F. The trap is designed for horizontal installation and includes a Stainless Steel float.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| FNPT | 2 1/2 in |
| Max. | 125 psi |
| Type | 108,000 lb/hr, C Pattern |
| Brand | MEPCO |
| Float Material | Stainless Steel |
| Manufacturer Series | 30 |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | SA30-9125G |
