Mepco 3G-OTH-71176 — Spesifikasi Teknis
The MEPCO Cast Iron H-Pattern Float & Thermostatic Steam Trap (MPN 44-530A) is a steam trap with a 1 1/4 in FNPT connection, rated for 3,000 lb/hr capacity, 30 psi maximum pressure, and 450°F maximum temperature. It features a stainless steel float and is designed for horizontal installation as part of the Manufacturer Series 44.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| FNPT | 1 1/4 in |
| Max. | 30 psi |
| Type | 3,000 lb/hr, H Pattern |
| Brand | MEPCO |
| Float Material | Stainless Steel |
| Manufacturer Series | 44 |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | 44-530A |
