Mepco 3G-OTH-71232 — Spesifikasi Teknis
The MEPCO Cast Iron H-Pattern Float & Thermostatic Steam Trap (MPN 46-830N) is a 2-inch FNPT steam trap with a maximum capacity of 12,500 lb/hr, a maximum pressure of 30 psi, and a maximum temperature of 450°F. It features a stainless steel float and is designed for horizontal installation. This unit is part of the MEPCO Series 46.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| FNPT | 2 in |
| Max. | 30 psi |
| Type | 12,500 lb/hr, H Pattern |
| Brand | MEPCO |
| Float Material | Stainless Steel |
| Manufacturer Series | 46 |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | 46-830N |
