Mepco 3G-OTH-71295 — Spesifikasi Teknis
The MEPCO 46-875N is a Cast Iron H-Pattern Float & Thermostatic Steam Trap designed for horizontal installation. It features a 2-inch FNPT connection, a maximum capacity of 5,000 lb/hr, and a maximum operating pressure of 75 psi with a maximum temperature of 450°F. The float is constructed from stainless steel, and the trap is part of the MEPCO Series 46.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| FNPT | 2 in |
| Max. | 75 psi |
| Type | 5,000 lb/hr, H Pattern |
| Brand | MEPCO |
| Float Material | Stainless Steel |
| Manufacturer Series | 46 |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | 46-875N |
