Mepco 3G-OTH-71346 — Spesifikasi Teknis
The MEPCO Cast Iron H-Pattern Float & Thermostatic Steam Trap (MPN 46-8125N) is a 2-inch FNPT steam trap with a maximum capacity of 4,500 lb/hr, a maximum pressure of 125 psi, and a maximum temperature of 450°F. It features a stainless steel float and is designed for horizontal installation. This unit is part of the MEPCO Series 46.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| FNPT | 2 in |
| Max. | 125 psi |
| Type | 4,500 lb/hr, H Pattern |
| Brand | MEPCO |
| Float Material | Stainless Steel |
| Manufacturer Series | 46 |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | 46-8125N |
