Ntn 3G-OTH-97148 — Spesifikasi Teknis
The NTN Ball Screw Support Bearing: 20X47 is a single, angular contact thrust bearing for ball screws, featuring a 20 mm bore and a 60° contact angle. This open bearing has a thermoplastic cage and is rated ABEC 7 precision. It is supplied as a single bearing (not matched) under the metric system, with the bearing industry number 20X47 and manufacturer part number BST20X47-1BP4.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Row | 1 |
| Bore | 20 mm |
| Type | 60°, Open, ABEC 7, Thermoplastic Cage |
| Brand | NTN |
| Bearing Type | Single Bearing |
| Contact Bearing Type | Angular Contact |
| Matched Bearing Type | Not Matched/Single Bearing |
| System Of Measurement | Metric |
| Bearing Industry Number | 20X47 |
| Manufacturer Part Number | BST20X47-1BP4 |
