Ntn 3G-OTH-97395 — Spesifikasi Teknis
The NTN Ball Screw Support Bearing: 40X90 is a single, angular contact thrust bearing for ball screws, featuring a 40 mm bore, a 60° contact angle, an open design, an ABEC 7 precision rating, and a thermoplastic cage. This metric bearing, identified by industry number 40X90 and manufacturer part number BST40X90-1BP4, is supplied as a single bearing with no matched pairing.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Row | 1 |
| Bore | 40 mm |
| Type | 60°, Open, ABEC 7, Thermoplastic Cage |
| Brand | NTN |
| Bearing Type | Single Bearing |
| Contact Bearing Type | Angular Contact |
| Matched Bearing Type | Not Matched/Single Bearing |
| System Of Measurement | Metric |
| Bearing Industry Number | 40X90 |
| Manufacturer Part Number | BST40X90-1BP4 |
