Ntn 3G-OTH-110048 — Spesifikasi Teknis
The NTN UCP-35 is a general purpose pillow block ball bearing with a 35 mm bore, featuring a cast iron housing and set screw locking. This metric unit has a maximum speed of 4,200 RPM, a shaft height of 47.5 mm, an overall length of 166.7 mm, and accepts M12 mounting bolts.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Type | Cast Iron, Set Screws |
| Brand | NTN |
| Shaft Ht | 47.5 mm |
| Overall Lg | 166.7 mm |
| Maximum Speed | 4,200 RPM |
| Mounting Bolt Size | M12 |
| System Of Measurement | Metric |
| Manufacturer Part Number | UCP-35 |
