Ntn 3G-OTH-100807 — Spesifikasi Teknis
The NTN 3 Bolt Flange Bearing is a food-grade flange-mount radial ball bearing with a 25 mm cylindrical bore, designed for metric mounting with M10 bolts. It features FDA/USDA-H1 solid grease lubrication and set screw locking, with dimensions of 67 mm length, 35.8 mm width, and 119 mm height (MPN SUCFB205FG1). No bearing cap is included.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Ht | 119 mm |
| Lg | 67 mm |
| Wd | 35.8 mm |
| Bore | 25 mm |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | M10 |
| Included Bearing Cap | None |
| System Of Measurement | Metric |
| Manufacturer Part Number | SUCFB205FG1 |
