Ntn 3G-OTH-113960 — Spesifikasi Teknis
The NTN 4 Bolt Flange Bearing is a general purpose flange-mount ball bearing with a 3/4 in cylindrical bore, cast iron housing, and set screw locking. It uses NLGI #3 equivalent lubricant, has a 7/16 in mounting bolt size, and measures 3 3/8 in length by 3 3/8 in height (MPN UCF204-012D1). This inch-system unit is designed for radial load applications.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Ht | 3 3/8 in |
| Lg | 3 3/8 in |
| Bore | 3/4 in |
| Type | Cast Iron, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | NLGI #3 Equivalent |
| Mounting Bolt Size | 7/16 in |
| System Of Measurement | Inch |
| Manufacturer Part Number | UCF204-012D1 |
