Ntn 3G-OTH-104640 — Spesifikasi Teknis
The NTN SUCF206-19 is a 4-bolt flange bearing of the radial ball type, designed as a food-grade flange-mount ball bearing. It features a 1 3/16 in cylindrical bore, stainless steel construction, and set screw locking, with dimensions of 4 1/4 in length and 1 37/64 in width. The bearing is lubricated with FDA/USDA-H1 solid grease and uses a 7/16 in mounting bolt size, with no included bearing cap.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Lg | 4 1/4 in |
| Wd | 1 37/64 in |
| Bore | 1 3/16 in |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | 7/16 in |
| Included Bearing Cap | None |
| System Of Measurement | Inch |
| Manufacturer Part Number | SUCF206-19 |
