Schneider 3G-OTH-41616 — Spesifikasi Teknis
The SCHNEIDER Overload Relay: Thermal Protection (SKU 19YD11, MPN LRD32L) is an IEC thermal overload relay with a 23 A – 32 A range, designed for use with TeSys Deca contactors (25 to 38 Amp models). It features 1NO/1NC auxiliary contacts, a maximum voltage rating of 690V AC, and phase loss sensitivity. The relay includes integrated bimetallic elements, eliminating the need for separate thermal units, and uses screw clamp terminals for connection.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Type | 1NO/1NC, Phase Loss Sensitivity, 23 A – 32 A |
| Brand | SCHNEIDER |
| Poles | 3 |
| Compatible Contactors | TeSys Deca (25 to 38 Amp Models) |
| Auxiliary Contact Form | 1NO/1NC |
| Maximum Voltage Rating | 690V AC |
| Phase Loss Sensitivity | Yes |
| Thermal Units Required | None (Relay Includes Integrated Bimetallic Elements) |
| Manufacturer Part Number | LRD32L |
| Terminal Connection Type | Screw Clamp Terminals |
| Compatible Contactor Series | TeSys Deca |
