Schneider 3G-OTH-41946 — Spesifikasi Teknis
The SCHNEIDER Overload Relay: Thermal Protection (MPN LR2D3555) is a 3-pole IEC thermal overload relay with integrated bimetallic elements, rated for 30 A – 40 A and a maximum voltage of 1000V AC. It features 1NO/1NC auxiliary contacts, phase loss sensitivity, and screw clamp terminals, designed for use with TeSys Deca contactors (80 to 95 Amp models).
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Type | 1NO/1NC, Phase Loss Sensitivity, 30 A – 40 A |
| Brand | SCHNEIDER |
| Poles | 3 |
| Compatible Contactors | TeSys Deca (80 to 95 Amp Models) |
| Auxiliary Contact Form | 1NO/1NC |
| Maximum Voltage Rating | 1000V AC |
| Phase Loss Sensitivity | Yes |
| Thermal Units Required | None (Relay Includes Integrated Bimetallic Elements) |
| Manufacturer Part Number | LR2D3555 |
| Terminal Connection Type | Screw Clamp Terminals |
| Compatible Contactor Series | TeSys Deca |
