Siemens 3G-OTH-67091 — Spesifikasi Teknis

Name: Siemens 3G-OTH-67091 Actuator: Dampers/Economizers, Proportional, Spring Return, 20 in-lb, 24V AC/DC, NEMA 1 / IP40 (MPN GQD151.1P). Key specifications — Manufacturer Part Number: GQD151.1P; Shaft Type: Set Screw Shaft Coupling; Shaft Rotation: CW/CCW; Stroke Degree: 90°; Plenum Rating: Plenum Rated; Power Rating: 3W; Input Voltage: 24V AC/DC; Brand: SIEMENS.
Brand: Siemens

The Siemens GQD151.1P is a fail-safe actuator with spring return for dampers and economizers, featuring a 90° stroke, CW/CCW shaft rotation, and a set screw shaft coupling. It operates on 24V AC/DC input with a 3W power rating and provides a 2 to 10V DC proportional output signal. This plenum-rated actuator is compatible with building automation systems and has a NEMA 1 / IP40 enclosure.

Lihat Produk & Minta Penawaran

Spesifikasi Teknis

Parameter	Nilai
Type	Proportional, Spring Return, 20 in-lb, NEMA 1 / IP40
AC/DC	24V
Brand	SIEMENS
Shaft Type	Set Screw Shaft Coupling
Power Rating	3W
Input Voltage	24V AC/DC
Output Signal	2 to 10V DC
Plenum Rating	Plenum Rated
Stroke Degree	90°
Shaft Rotation	CW/CCW
Manufacturer Part Number	GQD151.1P
Auxiliary Switch Included	No
Electrical Connection Type	Hardwired
For Use With Building Automation Systems	Building Automation System Compatible
