Siemens 3G-OTH-67584 — Spesifikasi Teknis
The Siemens GEB161.1U is a non-fail-safe, proportional damper actuator with a self-centering shaft and 177 in-lb torque. It operates on 24V AC/DC with a 0 to 10V DC output signal, providing 90° stroke with CW/CCW rotation. This hardwired, NEMA 2 / IP54 rated actuator is compatible with building automation systems.
Spesifikasi Teknis
| Parameter | Nilai |
|---|---|
| Type | Proportional, Non-Spring Return, 177 in-lb, Hardwired, NEMA 2 / IP54 |
| AC/DC | 24V |
| Brand | SIEMENS |
| Shaft Type | Self-Centering |
| Power Rating | 24VAC/VDC |
| Input Voltage | 24V AC/DC |
| Output Signal | 0 to 10V DC |
| Stroke Degree | 90° |
| Shaft Rotation | CW/CCW |
| Manufacturer Part Number | GEB161.1U |
| Auxiliary Switch Included | No |
| Electrical Connection Type | Hardwired |
| For Use With Building Automation Systems | Building Automation System Compatible |
